Removing the USB board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the computer base.
4 Follow the procedure from step 1 to step 4 in “Removing the hard drive”.
Procedure
1 Peel off the tape from the USB-board cable.
2 Open the routing clip and disconnect the USB-board cable from the USB
board.
3 Remove the screw that secures the USB board to the computer base.
45
