Secondary paper jam sequences on the printer control panel
Light sequence What you can do to access the jam
200.yy Paper jam
- On
- On
- On
Try one or more of the following:
• Remove Tray 1.
• Remove the photoconductor kit and toner
cartridge unit.
201.yy Paper jam
- On
- On
- On
Remove the photoconductor kit and toner
cartridge unit.
202.yy Paper jam
- On
- On
- On
Open the front door, and then open the rear
door.
Interpreting the printer control panel lights
