Next steps
1. Reconnect the battery cable.
2. Replace the base cover
3. Replace the SD memory card
4. Follow the procedure in after working inside your computer
System fan
Removing the system fan
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD memory card.
3. Remove the base cover.
4. Remove the battery.
Steps
1. Disconnect the VGA board cable [1], and the display cable [2, 3] from the system board .
64
Removing and installing components
