System specifications
Feature Specification
Chipset Integrated in the processor
DRAM bus width 64-bit
Flash EPROM SPI 128 Mbits
PCIe bus 100 MHz
External Bus
Frequency
DMI 3.0—8GT/s
Memory specifications
Feature
Specification
Memory
connector
Integrated in the processor
Memory capacity 4 GB and 16 GB
Memory type DDR4 SDRAM-2133 MHz
Minimum
memory
4 GB
Maximum
memory
16 GB
Storage specifications
This laptop supports one M.2 SATA SSD or M.2 PCIe NVMe SSD.
The options are:
● Up to 512 GB SATA SSD
● Up to 1 TB PCIe NVMe SSD
● Up to 512 GB NVMe SED SSD
Video specifications
Table 4. Video specifications
Feature Specifications
UMA controller Intel-Integrated HD Graphics 620Intel-Integrated HD Graphics
520 (available with Intel 6th Gen Core I only)
External display support
On system - eDP (internal display), HDMI
Type Integrated on system board
Intel 7th generation i3 / i5/ i7 series
NOTE: Supports one VGA, DisplayPort, HDMI through the docking station .
50 System specifications
