About Your Monitor | 17
Back View
Back view with monitor stand
Label Description Use
1 VESA mounting holes
(
100 mm x 100 mm -
behind attached VESA
Cover)
Wall mount monitor using VESA-compatible wall
mount kit (100 mm x 100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Stand release button Releases stand from monitor.
4 Kensington lock slot strip Remove the plastic strip covering the slot before
usi
ng the purchased lock.
5 Cable cover Offers the protection to the installed cables on the
rear
of the monitor.
6 Kensington lock slot Supports the use of Kensington lock to prevent
theft. (K
ensington lock not included)
7 Barcode serial number
labe
l
Refer to this label if you need to contact Dell for
technical support.
8 Cable clip Use to secure the cables by tightening the screw
on the clip.
9 Cable management slot Use to organize cables by placing them through
the slot.
