Dell Networking N4032 - Creating a Switch Stack; 2.2 Creating a Stack

Hardware Overview 11
Figure 2. Port LEDs
Locator LED • Blinking blue - Locator
function is enabled
• Solid blue - Locator
function is disabled
On back panel
a. The thermal sensors system temperature threshold is 75°C. When the threshold is exceeded, the
Temp LED lights up to Red.
Table 1. LED Definitions for System (Continued)
Feature Detailed Description Comment
