Dell OptiPlex 3070 Small Form Factor - Page 64

4. Route all the cables through the routing clips [1].
5. Align the cables with the pins on connectors on the system board and connect the following cables to the system board:
a) Power switch [2]
b) CPU power [3]
c) Intrusion switch [4]
64
Removing and installing components
