6. Connect the power cable, optical drive data cable and hard drive data cable [1, 2, 3].

7. Insert the hook on the I/O panel into the slot on the chassis and rotate to close the I/O panel [4].

8. Replace the screw to secure the I/O panel to the chassis [5].

Removing and installing components
