Installing the back cover
1. Align the notches on the back cover to the holes on the computer and press it until it snaps in.
2. Install the:
a. cable cover
b. stand
3. Follow the procedure in After Working Inside Your Computer.
Removing the speaker cover
1. Follow the procedure in Before Working Inside Your Computer.
2. Remove the:
a. stand
b. cable cover
c. back cover
3. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the speaker cover to the computer [1].
b. Slide the speaker cover to release it from the computer [2].
12
