Dell OptiPlex 7440 - Installing the Converter Board

4. Perform the following steps as shown in the illustration:
a. Remove the screws that secure the converter board to the chassis [1].
b. Lift the converter board away from the chassis [2].
Installing the converter board
1. Place the convertor board in its slot.
2. Tighten the screws to secure the converter board to the chassis.
3. Connect the converter-board cable and display-backlight cable to the connectors on the converter
board.
4. Install the:
a. speaker cover
b. cable cover
c. back cover
d. stand
5. Follow the procedure in After Working Inside Your Computer.
