Dell OptiPlex 760 - Page 187


10. Lower the heat sink onto the processor at a 45-degree angle so that one end of the heat sink fits securely under the tab opposite the release tab on
the retention base.

11. Re-assemble the shroud.

12. Replace the computer cover (see Replacing the Computer Cover).

13. Replace the cable cover, if used (see Attaching the Cable Cover).
Back to Contents Page

3
release lever






