Table 20. System Information
Feature Specification
System chipset
Intel Q87 chipset
Table 21. Expansion Bus
Feature Specification
Bus type USB 2.0, USB 3.0, SATA 3, and PCle G2
Bus speed 480 Mbps, 5 Gbps, 6 Gbps, and 5 Gbps
Table 22. Cards
Feature Specification
WLAN card
Intel Dual Band Wireless-AC 7260 (M.2)
802.11 ac
Bluetooth 4.0
WiDi (Wireless Display)
NOTE: For optimal performance, it is recommended
to use the wireless display feature with an access
point that supports 5 GHz standard.
Table 23. Drives
Feature Specification
Internally Accessible: 2.5-inch SATA drive bays
Table 24. External Connectors
Feature Specification
Audio:
Front panel one global headset and one microphone connector ( re-
taskable to headphone )
Network adapter one RJ–45 connector
Serial PS2 and serial connector (optional)
USB 2.0 (Front/Rear/Internal) 0/0/1
USB 3.0 (Front/Rear/Internal) 2/4/0
Video
• 15-pin VGA connector
• one 20-pin DisplayPort connector
• one optional HDMI or DisplayPort
52
