Steps
1. Slide the intrusion switch into the slot on the chassis.
2. Route the intrusion-switch cable through the routing guides on the chassis.
3. Connect the intrusion-switch cable to the connector on the system board.
Next steps
1. Install the side cover.
2. Follow the procedure in After working inside your computer.
System fan
Removing the system fan
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the front bezel.
4. Remove the 2.5-inch hard drive if applicable.
5. Remove the 3.5-inch hard drive if applicable.
6. Remove the disk-drive cage.
About this task
The following image indicates the location of the system fan and provides a visual representation of the removal procedure.
76
Removing and installing Field Replaceable Units (FRUs)
