Dell OptiPlex XE3 Tower - Installing SD Card Reader

Installing SD card reader
1. Insert the SD card reader into the slot on the front panel door [1].
2. Tighten the screw to secure the SD card reader to the front panel door [2].
3. Connect the SD card reader cable to the connector on the system board [3].
