4. Close the front panel door.
5. Install the:
a. front bezel
b. side cover
6. Follow the procedure in After working inside your computer.
Speaker
Removing speaker
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. side cover
b. front bezel
3. Open the front panel door.
4. To remove the speaker:
a. Disconnect the speaker cable from the connector on the system board [1].
b. Press the release tabs [2], and slide the speaker out of the slot [3].
40
Disassembly and reassembly
