CAUTION: Do not touch the processor socket pins, they are fragile and can be permanently damaged. Be
careful not to bend the pins in the processor socket when removing the processor out of the socket.
Installing processor
1. Place and align the processor on the socket such that the slots on the processor align with the socket keys [1].
CAUTION:
Do not use force to seat the processor. When the processor is positioned correctly, it engages
easily into the socket.
2. Close the processor shield by sliding it under the retention screw [2].
3. Lower the socket lever and push it under the tab to lock and secure the processor [3].
Disassembly and reassembly
53
