Dell OptiPlex XE3 Tower - Installing Memory Module

Installing memory module
1. Align the notch on the memory module with the tab on the memory module connector.
2. Insert the memory module into the memory module socket [1].
3. Press the memory module until the memory module retention tabs click into place [2].
Disassembly and reassembly
31
