Dell OptiPlex XE3 Tower - Page 35

5. To remove the PSU:
a. Remove the screw (3) to release the PSU from the computer chassis [1].
b. Press the release tab [2].
c. Slide and lift the PSU away from the computer [3].
Disassembly and reassembly
35
