Dell OptiPlex XE4 Tower - Page 43

Steps
1. Lift the pull tab to open the PCIe door.
2. Disconnect the 6-pin power cable from its connector on the powered add-in-card.
3. Hold and remove the powered add-in-card from its slot on the system board.
4. Close the PCIe door.
Removing and installing components
43
