Dell P120F - Solid State Drive Bracket; Removing the Solid State Drive Bracket

Solid state drive bracket
Removing the solid state drive bracket
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the M.2 2230 solid state drive or M.2 2280 solid state drive, as applicable.
About this task
The following images indicate the location of the solid state drive bracket and provide a visual representation of the removal
procedure.
Steps
1. Remove the screw (M2x4) that secures the solid state drive bracket to the palm-rest and keyboard assembly.
NOTE: For computers shipped with an NVIDIA GeForce RTX 4080 graphics card, remove the single screw (M2x4) that
secures the solid state drive bracket to the palm-rest and keyboard assembly.
