Dell P76F - Screw List

Screw list
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Base cover Palm-rest assembly M2x5 6
Battery Palm-rest assembly M2x3 5
Wireless-card bracket System board M2x3 1
Hard-drive assembly Palm-rest assembly M2x3 3
Solid-state drive Palm-rest and keyboard
assembly
M2x3 1
Touchpad-bracket Palm-rest assembly M2x3 3
Touchpad Palm-rest assembly M2x2 4
Fan Palm-rest assembly M2x3 2
Display hinges Palm-rest assembly M2.5x5 4
Power-adapter port Palm-rest assembly M2x3 1
I/O board Palm-rest assembly M2x3 1
Power button with
ngerprint reader
Palm-rest assembly M3x3 2
System board Palm-rest assembly M2x2 2
Keyboard bracket Keyboard M1.2x1.4 14
Keyboard Palm-rest assembly M1.2x1.4 14
Hinge brackets Display back-cover and
antenna assembly
M2.5x2.5 6
Hinge brackets Display back-cover and
antenna assembly
M2x3 2
5
14 Screw list
