Replacing the keyboard
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the keyboard with the screw holes on the palm-rest assembly.
2 Replace the 14 screws (M1.2x1.5) that secure the keyboard to palm-rest assembly.
3 Align the screws holes on the keyboard bracket with the screw holes on the keyboard.
4 Replace the 14 screws (M1.4x2) that secure the keyboard bracket to keybaord.
5 Adhere the tape that secures the keyboard bracket to the keyboard.
39
62 Replacing the keyboard
