Removing the camera
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the fan.
4 Remove the heat sink.
5 Remove the display assembly.
6 Follow the procedure from step 1 to step 6 in "Removing the display panel".
Procedure
1 Using a plastic scribe, gently loosen the camera module from the display-panel assembly.
2 Roll over the camera module until it is released from the black adhesive tape and the camera cable is disconnected from the camera
module.
44
74 Removing the camera
