Dell PowerConnect 2824 User Manual

3
Contents
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PowerConnect 2808
. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PowerConnect 2816
. . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PowerConnect 2824 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PowerConnect 2848
. . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Summary of PowerConnect Models
. . . . . . . . . . . . . . . . . . . 11
Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
MAC Address Supported Features . . . . . . . . . . . . . . . . . . . . 13
Layer 2 Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
VLAN Supported Features
. . . . . . . . . . . . . . . . . . . . . . . . 14
Spanning Tree Protocol Features . . . . . . . . . . . . . . . . . . . . . 15
Class of Service (CoS) Features
. . . . . . . . . . . . . . . . . . . . . 16
Ethernet Switch Management Features
. . . . . . . . . . . . . . . . . . 16
2 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . 17
Switch Port Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . 17
PowerConnect 28xx Front and Back Panel Port Description . . . . . . . 17
Physical Dimensions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
LED Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Power LED
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Managed Mode LED
. . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan LED (2824/2848 only)
. . . . . . . . . . . . . . . . . . . . . . . 22
Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Managed Mode Button
. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Switch Ventilation Fan
. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cables, Port Connections, and Pinout Information
. . . . . . . . . . . . . . 24
1000BASE-T Cable Requirements. . . . . . . . . . . . . . . . . . . . 24
RJ-45 Connections for 10/100/1000BASE-T Ports. . . . . . . . . . . . 24
SFP Ports
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Dell PowerConnect 2824 Specifications

General

Throughput	35.6 Mpps
MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10/100/1000 Mbps
10G support	No
Number of VLANs	64
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1W, IEEE 802.1X, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3x
Dimensions (WxDxH)	330 x 230.5 x 42 mm
Power requirements	100 V
Networking features	Gigabit Ethernet
Connectivity technology	Wired
Dimensions (W x D x H) (imperial)	13 x 9.1 x 1.65 \
DHCP features	DHCP server, DHCP client
Switch type	Unmanaged
Switch layer	-
Data link protocols	Ethernet
Supported network protocols	IGMPv2, GARP, GVRP, GMP, IPv6
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
Product color	Black
Input current	1 A
Heat dissipation	95.5 BTU/h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2500 g
