Dell PowerConnect 28xx Systems User Guide 67
• Port — The port to which the fiber cable is connected.
•
Temperature — Internally measured transceiver temperature.
•
Voltage — Internally measured supply voltage.
•
Current — Measured TX bias current.
•
Output Power — Measured TX output power in milliwatts.
•
Input Power — Measured RX received power in milliwatts.
•
TXTransmitter Fault — Transmitter fault.
Finisair transceivers do not support the transmitter fault diagnostic testing.
• LOSLoss of Signal — Loss of signal.
•
Data Ready — The transceiver has archived power up and data is ready.
•
N/A — Not Available, N/S - Not Supported, W - Warning, E - Error.
Fiber Optic analysis feature works only on SFPs that support the digital diagnostic standard SFF-4872.
