Dell PowerEdge R730 User Manual

NOTE: This procedure applies only to PowerEdge R730xd systems.
Steps
1. Align the notches on the backplane with the notches on the chassis.
2. Lift the release pin and slide the backplane toward the back of the chassis until firmly seated.
3. Release the release pin to lock the backplane to the chassis.
4. Reconnect all the cables to the backplane.
Next steps
1. Install both the hard drives in their original location.
2. Follow the procedure listed in After working inside your system.
Tape backup unit (optional)
The tape backup unit is supported only on 2.5 inch hard-drive systems of PowerEdge R730.
Removing the tape backup unit
Prerequisites
1. Ensure that you read the Safety instructions.
2. Follow the procedure listed in Before working inside your system.
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that came with the product.
Steps
1. Disconnect the power and data cables from the back of the tape backup unit.
Note the routing of the power and data cables inside the chassis as you remove them from the
system board and the tape backup unit. You must route these cables properly when you replace
them to prevent them from being pinched or crimped.
2. To remove the tape backup unit, press the release tab and slide the tape backup unit out of the tape
backup unit slot.
NOTE: If the tape backup unit is being permanently removed, install a tape backup unit blank by
sliding it into the slot until it snaps into place.
NOTE: The procedure to install and remove the tape backup unit blank is similar to that of the
tape backup unit.
NOTE: Tape backup unit blank must be installed in empty tape backup unit slot to maintain FCC
certification of the system. The blank also keeps dust and dirt out of the system and aid in
proper cooling and airflow inside the system.
165

Dell PowerEdge R730 Specifications

General

Display	LCD
Built-in display	Yes
Dell E-Value Code	PER730_EL0001A_Q1FY18_FG0011_BTP
HDD speed	10000 RPM
RAID levels	0, 1, 5, 6, 10, 50, 60
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD±RW
Supported HDD sizes	2.5 \
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	1
Number of HDDs supported	8
Supported storage drive interfaces	SAS, Serial ATA III
Tcase	74 °C
Bus type	QPI
Stepping	R0
Scalability	2S
Processor code	SR2R6
Processor cache	20 MB
Processor model	E5-2620V4
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v4
Processor socket	LGA 2011-v3
Processor threads	16
Processor codename	Broadwell
Motherboard chipset	Intel C610
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	45 x 52.5 mm
Processor boost frequency	3 GHz
Processor operating modes	64-bit
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68.3 GB/s
Maximum internal memory supported by processor	1536 GB
Performance management	Dell OpenManage
Operating system installed	No
Compatible operating systems	Windows Server 2008 SP2 (32/64 bit) Windows Server 2012 SP2 (32/64 bit) Windows Server 2008/2012 R2 (64 bit) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware ESX
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory layout (slots x size)	1 x 8 GB
Power supply	750 W
Power supply input frequency	50 - 60 Hz
LAN controller	Broadcom 5720
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Chassis type	Rack (2U)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express x8 slots	6
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Processor ARK ID	92986
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	684 mm
Width	440 mm
Height	87.3 mm
Weight	31400 g
