Dell PowerEdge R730 User Manual

Menu Item Description
Authorized
Signature
Database
Imports, exports, deletes, or restores entries in the Authorized Signature Database
(db).
Forbidden
Signature
Database
Imports, exports, deletes, or restores entries in the Forbidden Signature Database
(dbx).
Miscellaneous Settings screen details
You can use the Miscellaneous Settings screen to perform specific functions such as updating the asset
tag, and changing the system date and time.
You can view the Miscellaneous Settings screen by clicking System Setup Main Menu → System BIOS →
Miscellaneous Settings.
The Miscellaneous Settings screen details are explained as follows:
Example
Menu Item Description
System Time Enables you to set the time on the system.
System Date Enables you to set the date on the system.
Asset Tag Displays the asset tag and enables you to modify it for security and tracking
purposes.
Keyboard
NumLock
Enables you to set whether the system boots with the NumLock enabled or
disabled. By default the Keyboard NumLock is set to On.
NOTE: This option does not apply to 84-key keyboards.
F1/F2 Prompt on
Error
Enables or disables the F1/F2 prompt on error. By default, F1/F2 Prompt on Error is
set to Enabled. The F1/F2 prompt also includes keyboard errors.
Load Legacy
Video Option
ROM
Enables you to determine whether the system BIOS loads the legacy video (INT
10H) option ROM from the video controller. Selecting Enabled in the operating
system does not support UEFI video output standards. This field is only for UEFI
boot mode. You cannot set this to Enabled if UEFI Secure Boot mode is enabled.
In-System
Characterization
This option enables or disables In-System Characterization. By default, In-System
Characterization is set to Disabled. The two other options are Enabled and
Enabled - No Reboot.
NOTE: The default setting for In-System Characterization is subject to change
in future BIOS releases.
When enabled, In-System Characterization (ISC) executes during POST upon
detecting relevant change(s) in system configuration to optimize system power and
performance. ISC takes about 20 seconds to execute, and system reset is required
for ISC results to be applied. The Enabled - No Reboot option executes ISC and
continues without applying ISC results until the next time system reset occurs. The
Enabled option executes ISC and forces an immediate system reset so that ISC
49

Dell PowerEdge R730 Specifications

General

Display	LCD
Built-in display	Yes
Dell E-Value Code	PER730_EL0001A_Q1FY18_FG0011_BTP
HDD speed	10000 RPM
RAID levels	0, 1, 5, 6, 10, 50, 60
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD±RW
Supported HDD sizes	2.5 \
Total storage capacity	300 GB
Maximum storage capacity	- TB
Number of HDDs installed	1
Number of HDDs supported	8
Supported storage drive interfaces	SAS, Serial ATA III
Tcase	74 °C
Bus type	QPI
Stepping	R0
Scalability	2S
Processor code	SR2R6
Processor cache	20 MB
Processor model	E5-2620V4
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v4
Processor socket	LGA 2011-v3
Processor threads	16
Processor codename	Broadwell
Motherboard chipset	Intel C610
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	45 x 52.5 mm
Processor boost frequency	3 GHz
Processor operating modes	64-bit
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Supported processor sockets	LGA 2011-v3 (Socket R)
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	68.3 GB/s
Maximum internal memory supported by processor	1536 GB
Performance management	Dell OpenManage
Operating system installed	No
Compatible operating systems	Windows Server 2008 SP2 (32/64 bit) Windows Server 2012 SP2 (32/64 bit) Windows Server 2008/2012 R2 (64 bit) Windows HPC Server 2008 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware ESX
Memory slots	24x DIMM
Internal memory	8 GB
Memory clock speed	2400 MHz
Memory layout (slots x size)	1 x 8 GB
Power supply	750 W
Power supply input frequency	50 - 60 Hz
LAN controller	Broadcom 5720
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Chassis type	Rack (2U)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express x8 slots	6
PCI Express slots version	3.0
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Processor ARK ID	92986
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00

Weight and Dimensions

Depth	684 mm
Width	440 mm
Height	87.3 mm
Weight	31400 g
