Dell PowerEdge R730 - Cooling Shroud

7. expansion-card riser 3 8. network daughter card
9. expansion-card riser 2 10. expansion-card riser 1
11. hard-drive backplane
Figure 20. Inside the system—PowerEdge R730xd
1. cooling-fan in the cooling-fan assembly (6) 2. processor (2)
3. DIMMs (24) 4. internal USB port
5. hard-drive backplane (back) 6. vFlash media slot
7. hard drive (2) (back) 8. power supply unit (2)
9. expansion-card riser 3 10. network daughter card
11. expansion-card riser 2 12. expansion-card riser 1
13. hard-drive backplane
Cooling shroud
59
