DellPowerVault™TL4000/TL2000FailoverGuide


7|Page 12/31/09 version 2.0
Failoverconfiguration
(onehostwithtwoHBAs,andtwoSASdrives)
MainPath
Failover Path

Figure3:ReferenceConfiguration3
FailoverReferenceConfiguration4:
OneHostwithdualFibreChannelHBAs,twoFibreChannelswitchesandaDellPowerVault™
withtwoFibreChanneldrives
Inthisconfiguration,failoveroccursifoneormoreofthefollowingoccurs:
‐Oneofthedrivesfails(hardwarefailureorisdrivedisconnectedfromtheHBAport)
‐OneoftheHBAcontrollersfails
‐Oneoftheswitchesfails
ThephysicalconnectionofthisconfigurationisshowninFigure4.
ImportantNote:DellRecommendsFibreChanneldrivestobesamegeneration.ForHeterogonous
configurationsrefertosection:Heterogonous ValidatedConfigurations

Alwaysrefertowww.dell.com\supportforlatestdocumentationandupdates

