Failoverconfiguration
(HostwithdualportHBAs,twoFCswitches,andtwoFCdrives)
MainPath
Failover Path

Figure4:ReferenceConfiguration4
FailoverReferenceConfiguration5:
TwohostswithdualFibreChannelHBAs,twoFibreChannelswitchesandoneDell
PowerVault™withtwoFibreChanneldrives
Inthisconfiguration,failoveroccursifoneormoreofthefollowingoccurs:
‐Oneofthedrivesfails(hardwarefailureorisdrivedisconnectedfromtheHBAport)
‐OneoftheHBAcontrollersfails
‐Oneoftheswitchesfails
ThephysicalconnectionofthisconfigurationisshowninFigure5.
ImportantNote:DellRecommendsFibreChanneldrivestobesamegeneration.ForHeterogonous
configurationsrefertosection:Heterogonous ValidatedConfigurations

