Constantly
blinking amber
light
Fatal battery failure with AC adapter present. Fatal battery, replace the battery.
Light off Battery in full charge mode with AC adapter present.
White light on Battery in charge mode with AC adapter present.
Diagnostic LED
Occasionally the computer may indicate bicolor flashes on Battery Charge LED. A specific blink pattern, flashing a pattern of
amber, followed by white, and then the same pattern repeats.
NOTE: The diagnostic pattern consists of a two-digit number that is represented by a first group of amber LED blinks (1
through 9), followed by a 1.5-second pause with the LED off, and then a second group of LED blinks (1 through 9) in white.
Followed by a three-second pause, with the LED off, before repeating over again. Each LED blink takes 0.5 s.
The system does not shut down when displaying the Diagnostic Error Codes. Diagnostic Error Codes supersedes any other use
of the LED. For instance, on laptops, battery codes for Low Battery or Battery Failure situations are not displayed when the
Diagnostic Error Codes are being displayed:
Table 11. LED pattern
Blinking
pattern
Problem Description Suggested Resolution
Ambe
r
White
2 1 processor processor failure
2 2 system board, BIOS ROM system board, covers BIOS corruption or ROM error
2 3 memory no memory/no RAM detected
2 4 memory memory failure/RAM failure
2 5 memory invalid memory installed
2 6 system board; chipset system board/ chipset error
2 7 display display failure
3 1 RTC power failure coin-cell battery failure
3 2 PCI/Video PCI/Video card/chip failure
3 3 BIOS recovery 1 recovery image nor found
3 4 BIOS recovery 2 recovery image found but invalid
44 Diagnostics
