Dell Precision 5510 User Manual

Working on your computer
Topics:
• Turning off Your Computer
•
Before working inside your computer
• After working inside your computer
Turning off Your Computer
CAUTION: To avoid losing data, save and close all open files and exit all open programs before you turn off your
computer.
You can turn off your computer in two ways :
1. Using the power button
2. Using the charms menu
Using power button
1. Press and hold the Power button
to turn off the screen.
Using charms
1. Swipe from the right edge of the display to access the Charms menu.
2. Touch Settings
—> Power —> Shut down to turn off the computer.
Before working inside your computer
1. Ensure that your work surface is flat and clean to prevent the computer cover from being scratched.
2. Turn off your computer.
3. If the computer is connected to a docking device (docked), undock it.
4. Disconnect all network cables from the computer (if available).
CAUTION:
If your computer has an RJ45 port, disconnect the network cable by first unplugging the cable
from your computer.
5. Disconnect your computer and all attached devices from their electrical outlets.
6. Open the display.
7. Press and hold the power button for few seconds, to ground the system board.
CAUTION:
To guard against electrical shock unplug your computer from the electrical outlet before
performing Step # 8.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by
periodically touching an unpainted metal surface at the same time as touching a connector on the back
of the computer.
8. Remove any installed ExpressCards or Smart Cards from the appropriate slots.
1
Working on your computer 5

Dell Precision 5510 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Black, Silver
Market positioning	Business
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
FSB Parity	No
Processor cache	8 MB
Processor cores	4
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1500M v5
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel CM236
Processor code	SR2FN
Processor ARK ID	89608
Processor package size	42 x 28 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
On-board graphics card ID	0x191D
Discrete graphics card model	NVIDIA® Quadro® M1000M
On-board graphics card model	Intel® HD Graphics P530
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
HDD size	2.5 \
HDD speed	7200 RPM
HDD capacity	500 GB
SSD capacity	256 GB
HDD interface	SATA
Storage media	HDD+SSD
Total storage capacity	756 GB
Compatible memory cards	SD, SDHC, SDXC
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	2 x 8 GB
Intel segment tagging	Professional
Panel type	IGZO
Display surface	-
Display diagonal	15.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	400 cd/m²
Native aspect ratio	16:9
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Front camera resolution	1280 x 720 pixels
Front camera resolution (numeric)	0.92 MP
Audio system	MaxxAudio Pro
Speakers manufacturer	Waves
Number of built-in speakers	2
Cable lock slot type	Kensington
AC adapter power	130 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	6.67 A
AC adapter output voltage	19.5 V
Battery voltage	11.4 V
Battery capacity	56 Wh
Battery life (max)	- h
Number of battery cells	3
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Operating system installed	Windows 7 Professional
Pointing device	Touchpad

Weight and Dimensions

Depth	235.43 mm
Width	357.23 mm
Height	11.48 mm
Weight	1780 g
