Setting up the monitor
Attaching the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for the stand that
was shipped with your monitor. If you are attaching a stand that you
purchased from any other source, follow the setup instructions that
were included with the stand.
To attach the monitor stand:
1.
Follow the instructions on the flaps of carton to remove the stand from the
top cushion that secures it.
2.
Connect the stand base to the stand riser.
3.
Open the screw handle on the stand base and tighten the screw to secure the
stand riser to the stand base.
4.
Close the screw handle.
3
2
1
4
5.
Slide the tabs on the stand assembly into the slots on the monitor and press
the stand assembly down to snap it into place.
5
6.
Place the monitor upright.
