Dell S3423DWC User Manual

Operating your monitor │ 55
Setting the KVM switch
The built-in KVM switch allows you to control up to 2 computers from a single set
of keyboard and mouse connected to the monitor.
When connecting HDMI + USB-B to computer 1 and USB-C to computer 2, make
sure USB for HDMI is assigned to USB-B .
USB
HDMI 2.0
HDMI 2.0
USB-C
1
3
1
32
2
Display
Brightness / Contrast
Dell 34 Monitor
Input Source
Color
Menu
Audio
Menu
Others
Others
PersonalizePersonalize
Audio
USB-B
USB-C
PIP/PBP
USB Selection
HDMI 1
HDMI 2
NOTE: The USB-C connection currently supports video and data
transfer.
NOTE: As the USB-C port supports the USB-C Alternate Mode, there
is no need to set USB for USB-C.
NOTE: When connecting to different video input sources not shown
above, follow the same method to make correct settings for USB to
pair the ports.

Dell S3423DWC Specifications

General

Panel type	VA
Color gamut	99 %
Pixel pitch	0.2318 x 0.2318 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Response time (fast)	5 ms
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Digital vertical frequency	48 - 100 Hz
Digital horizontal frequency	30 - 160 kHz
Display brightness (typical)	350 cd/m²
High Dynamic Range (HDR) supported	No
AMD FreeSync type	FreeSync
RMS rated power	10 W
Number of speakers	2
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	65 W
USB Type-C downstream ports quantity	0
Number of USB Type-B upstream ports quantity	1
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	31 W
Package depth	942.34 mm
Package width	223.52 mm
Package height	449.58 mm
Package weight	15210 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Cables included	AC, USB Type-A, USB Type-C to USB Type-C
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	217.05 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9740 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.03 mm
Height (without stand)	364.5 mm
Weight (without stand)	6650 g
