S4100–ON Series switch
The following sections describe the Dell EMC S4100–ON Series (S4128F-ON and S4148F-ON) switch:
Topics:
• Introduction
• Features
• Physical dimensions
• System status
• LED display
• Prerequisites
• S4100–ON Series congurations
• Luggage tag
Introduction
The S4100–ON Series (S4128F-ON and S4148F-ON) is a one rack unit (RU), full-featured xed form-factor top-of-rack (ToR)
10/25/40/50/100GbE switch for 10G servers with small form-factor pluggable plus (SFP+), quad small form-factor pluggable plus (QSFP
+), and quad small form-factor pluggable (QSFP28) ports.
NOTE
: For specic port prole details, see the OS10 Enterprise Edition User
Guide .
The S4100F-ON Series supports the following congurations:
Table 1. S4100-ON Series supported
congurations
S4128F-ON S4148F-ON
28 x 10G + 2 x 100G 48 x 10G + 4 x 100G
28 x 10G + 2 x 40G 48 x 10G + 6 x 40G
28 x 10G + 4 x 50G 48 x 10G + 8 x 50G
28 x 10G + 8 x 25G 48 x 10G + 16 x 25G
36 x 10G 72 x 10G
The following table lists the S4100–ON Series I/O-side details:
Table 2. S4100–ON Series I/O-side details
Platform Description
S4128F-ON
• 28 xed 10GbE SFP+ ports
• 2 xed 100GbE QSFP28 ports
• seven-segment stacking indicator
• 1 micro-USB-B console port
2
S4100–ON Series switch 7
