LED Indicators
Front panel
• One dual-color LED indicator for system status
• One single-color LED indicator for power status
• Identication button with a single-color LED
Hard drive carrier
• One single-color activity LED
• One dual-color LED status indicator per drive
Storage controller
• Two single-color LEDs per Ethernet port indicating activity and link speed
• One dual-color LED per SAS connector indicating port activity and status
• One single-color LED indicating status
• One single-color LED indicating system faults
• One single-color LED for system identication
Power supply/cooling fan One dual-color LED handle indicating power supply and cooling fan status
Power Supply Units (PSU)
AC power supply (per power
supply)
PSU Type 1 PSU Type 2 (Japan Only) PSU Type 3
Maximum output power 1485 W 1485 W 1378 W
Maximum input power 1688 W 1707 W 1584 W
Maximum input current 8.8 A 17.5 A 16 A
Maximum inrush current 55 A for 10 ms or less 55 A for 10 ms or less 55 A for 10 ms or less
Nominal input voltage operating
range
200–240 VAC 100–240 VAC 100–240 VAC
Nominal input frequency 50/60 Hz 50/60 Hz 50/60 Hz
Thermal output/heat dissipation 693 BTU per hour 757 BTU per hour 703 BTU per hour
Available Hard Drive Power (Per Slot)
Supported hard drive power consumption
(continuous)
Up to 1.2 A at +5 V
Up to 0.5 A at +12 V
Physical
Height 13.34 cm (5.25 in.)
Width 44.50 cm (17.5 in.)
Depth
SCv3000 81.91 cm (32.25 in.)
SCv3020 78.27 cm (31 in.)
Approximate weight (maximum conguration)
SCv3000 45 kg
SCv3020 43 kg
Approximate weight without drives 32.5 kg (72 lb)
SCv3000 and SCv3020 Storage System Technical Specications
21

Dell SCv3000 Specifications

General

HDD speed	10000 RPM
Storage drive size	3.5 \
Storage drive capacity	900 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	6.3 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	7
Number of storage drives supported	16
USB connectivity	-
Chassis type	Rack (3U)
Product color	Black, Grey
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	1485 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Dell E-Value Code	SCv3000FC

Weight and Dimensions

Depth	785 mm
Width	445 mm
Height	133.3 mm
