SCv3000 and SCv3020 Storage System Technical
Specications
This appendix contains the technical specications for the SCv3000 and SCv3020 storage system.
Technical Specications
The technical specications of the SCv3000 and SCv3020 storage systems are displayed in the following tables.
Drives
SAS hard drives
SCv3000 Up to 16 3.5-in. hot-swappable hard drives (12 Gb SAS)
SCv3020 Up to 30 2.5-in. SAS hot-swappable hard drives (12 Gb SAS)
Storage Controllers
Storage controllers
Up to two hot-swappable storage controllers with one I/O card slot and one
optional mezzanine card per storage controller.
Each storage controller has an internal battery backup unit. Write cache is
mirrored between the two storage controllers. If a power failure occurs, the
battery backup unit provides power to the storage controller so that the write
cache can be saved to an SSD within the storage controller.
Storage Connectivity
Congurations
SCv3000 Supports a total of 150 drives and up to 120 drives on a single SAS
chain.
SCv3020 Supports a total of 150 drives and up to 134 drives on a single SAS
chain.
Redundant Array of Independent Disks (RAID)
Controller Two hot-swappable storage controllers
Management RAID management using the Dell Storage Manager
Back-Panel Ports Connectors (per Storage Controller)
Fibre Channel, iSCSI, or SAS front-end
connectors
Connection to a Fiber Channel fabric, iSCSI network, or a direct connection to
servers with SAS HBAs
Ethernet connectors MGMT – 1 Gbps embedded Ethernet port used for Storage Center management
SAS back-end connectors 12 Gb SAS ports for connections to expansion enclosures
NOTE: SAS connectors are SFF-8644 compliant.
Serial connector (micro USB) Used for initial conguration and support-only functions
20
SCv3000 and SCv3020 Storage System Technical Specications

Dell SCv3000 Specifications

General

HDD speed	10000 RPM
Storage drive size	3.5 \
Storage drive capacity	900 GB
Storage drive interface	Serial Attached SCSI (SAS)
Storage drives installed	Yes
Installed storage drive type	HDD
Total installed storage capacity	6.3 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	7
Number of storage drives supported	16
USB connectivity	-
Chassis type	Rack (3U)
Product color	Black, Grey
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	1485 W
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Dell E-Value Code	SCv3000FC

Weight and Dimensions

Depth	785 mm
Width	445 mm
Height	133.3 mm
