Dell Studio 1435 - Display Panel; Display Bezel; Removing the Display Bezel; Replacing the Display Bezel


11. Slide the battery into the bay until it clicks into place.
Display Bezel

Removing the Display Bezel

1. Follow the instructions in Removing the Display Assembly.

2. Using your fingertips, carefully pry up the inside edge of the display bezel.

3. Remove the display bezel.

Replacing the Display Bezel

1. Align the display bezel over the display panel, and gently snap the bezel into place.

2. Follow the instructions in Replacing the Display Assembly.
Display Panel

Removing the Display Panel

1. Follow the instructions in Removing the Display Assembly.

2. Remove the display bezel (see Removing the Display Bezel).

3. Remove the four screws securing the display panel.

4. Remove the two screws securing the inverter board.
NOTICE: The display bezel is extremely fragile. Be careful when removing it to prevent damaging the bezel.
1
display bezel
