while pulling on the outside.
Replacing the Palm Rest
1. Align the palm rest with the computer base and gently snap the palm rest in place.
2. Connect the power sensor cable, touch pad cable, and fingerprint cable (optional) to the respective system board connectors.
3. Replace the screws on the top of the palm rest.
4. Turn the computer over and replace the eleven screws in the computer base.
5. Replace the keyboard (see Replacing the Keyboard).
6. Replace the center control cover (see Replacing the Center Control Cover).
7. Replace the base cover (see Replacing the Base Cover).
8. Slide the battery into the bay until it clicks into place.
