Dell Studio 1435 - Page 39


4. Connect the speaker cable to the system board connector (see Replacing the Speakers).

5. Replace the palm rest (see Replacing the Palm Rest).

6. Replace the keyboard (see Replacing the Keyboard).

7. Replace the center control cover (see Replacing the Center Control Cover).

8. Replace the processor heat sink and processor (see Replacing the Processor Heat Sink and Installing the Processor).

9. Replace the hard drive (see Replacing the Hard Drive).

10. Reinstall the memory modules and Mini-Cards, if any.

11. Reinstall the ExpressCards in the ExpressCard slot, if any.

12. Turn on the computer.

13. Insert the CD that accompanied the replacement system board into the appropriate drive. Follow the instructions that appear on the screen.
Back to Contents Page

NOTICE: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may result in
damage to the computer.
NOTE: After you have replaced the system board, enter the computer Service Tag into the BIOS of the replacement system board.
