Replacing Memory Module(s)
Dell™StudioHybridServiceManual
Removing Memory Module(s)
Installing Memory Module(s)
You can increase your computer memory by installing memory modules on the system board. See "Specifications" in your Setup Guide for information on the
memory supported by your computer. Install only memory modules intended for your computer.
Your computer has two user-accessible SO-DIMM sockets located one below the other.
Removing Memory Module(s)
1. Follow the procedure in Before You Begin.
2. Remove the computer cover (see Removing the Computer Cover).
3. Remove the drive cage (see Removing the Drive Cage).
4. To locate the memory modules, (see Inside View of Your Computer).
5. Push apart the securing clips until the module pops up.
6. Remove the module from the slot.
Installing Memory Module(s)
1. Follow the procedure in Before You Begin.
2. Align the notch in the module edge connector with the tab in the connector slot.
3. Slide the module firmly into the slot at a 45-degree angle, and rotate the module down until it clicks into place. If it is not firmly seated, remove the
module and reinstall it.
4. Replace the drive cage (see Installing the Drive Cage).
5. Replace the computer cover (see Installing the Computer Cover).
6. Connect your computer and devices to electrical outlets, and then turn them on.
7. When the message appears stating the memory size has changed, press <F1> to continue.
8. Log on to your computer.
