3. Align the power switch holder with the corresponding slot on the chassis and gently push the power switch holder until it snaps into place.
4. Connect the power cable to the system board(F_PANEL_CON1).
5. Replace the RF receiver board (see Installing the RF Receiver Board).
6. Replace the front panel (see Installing the Front I/O Panel).
7. Replace the drive cage (see Installing the Drive Cage).
8. Replace the computer cover (see Installing the Computer Cover).
