Dell Vostro 1540 - USB Board Replacement

13
Removing The USB Board
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the keyboard.
4. Remove the optical drive.
5. Remove the palm rest.
6. Disconnect the USB board cable from the system board.
7. Remove the screw that secures the USB board.
35
