Removing The DC-in Port And The
Bracket
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the hinge cover.
4. Remove the keyboard.
5. Remove the palm rest.
6. Remove the display assembly
7. Disconnect the DC-in cable from the system board.
8. Remove the screw that secures the DC-in port and bracket.
55
