Dell Vostro 1540 - Microphone Replacement

14
Removing The Microphone
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the keyboard.
4. Remove the palm rest.
5. Disconnect the microphone cable from the system board.
6. Lift up and remove the microphone from its compartment.
37
