Removing The Low-Voltage
Differential Signaling (LVDS) Cable
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the hinge cover.
4. Remove the keyboard.
5. Remove the optical drive.
6. Remove the palm rest.
7. Remove the display assembly.
8. Remove the display bezel.
9. Remove the display panel.
10. Peel off the tape securing the LVDS cable connection.
11. Disconnect the LVDS cable from the display panel.
