Removing The Speakers
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the SD memory card.
4. Remove the keyboard.
5. Remove the optical drive.
6. Remove the memory module.
7. Remove the palm rest.
8. Remove the hard drive.
9. Remove the WLAN card.
10. Remove the CPU fan assembly and the heatsink.
11. Remove the system board.
12. Release the speaker cable from the routing channel.
13. Press the securing latches and lift up the left speaker.
