Dell Vostro 1540 - Installing the Low-Voltage Differential Signaling (LVDS) Cable

12. Peel off the entire display cable from the adhesive affixing it to the display panel.
Installing The Low-Voltage Differential Signaling
(LVDS) Cable
1. Attach the display cable to the display panel.
2. Connect the display cable connector to the display panel and affix the tape to
secure it.
3. Install the display panel.
4. Install the display bezel.
5. Install the display assembly.
6. Install the palm rest.
7. Install the optical drive.
8. Install the keyboard.
68
