Dell Vostro 1540 - Processor Replacement

16
Removing The Processor
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the keyboard.
4. Remove the palm rest.
5. Remove the CPU fan assembly and the heatsink.
6. Rotate the processor-cam screw in a counter-clockwise direction.
7. Lift up the processor and remove it from the computer.
