Steps
NOTE: Before removing the display hinge caps, open the display hinges to 140 degrees.
1. Pinch the left hinge cap in the center.
2. Using a plastic scribe pry the inner side of the left hinge cap and remove it from the left hinge.
3. Pinch the right hinge cap in the center.
4. Using a plastic scribe pry the inner side of the right hinge cap and remove it from the right hinge.
Installing the hinge caps
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the hinge caps and provides a visual representation of the installation procedure.
Removing and installing components
55
